9500N-000 Module
This module 9500N-000 is for our temperature detector serial. Using 8*8 Thermopile Array sensor to capture the tempera-ture of human body. It can measures the thermal energy to capture and calculate through a contactless method. And it send out temperature by UART and USB 2.0 interface.
Module Specification
● Module Specification
¹ Power is from USB bus power 5V
Power consumption is about 100mW
² Data output: USB port and UART port from
module
³ 8*8 Thermolpile Array sensor detect
10~15uM wavelength
⁴ Detect area : forehead area 30~50 cm
⁵ Temperature accuracy : ±0.3° C
● Control Board Specification
¹ Low power MCU from NXP
² Out Interface :
- USB and UART for data output
- Power from USB or connector
³ UART specification : 19200, 8N1
Thermopile Array sensor specification
¹ Resolution : 8*8 thermal image
² FOV : 35 degree
³ Distance : 30 to 40 cm
